雙極性晶體管

二極管

ESD保護、TVS、濾波和信號調節ESD保護

MOSFET

氮化鎵場效應晶體管(GaN FET)

絕緣柵雙極晶體管(IGBTs)

模擬和邏輯IC

汽車應用認證產品(AEC-Q100/Q101)

接口

全面的I2C GPIO擴展器和轉換器產品組合

我們的接口系列由GPIO擴展器和轉換器組成,通過提供更低功耗的技術確保實現高性能信號傳輸,從而增強系統功能,并提高可靠性。

主要特性和優勢

  • 寬電源電壓范圍
  • 低傳播延遲
  • 低功耗:2.5 µA(最大值)
  • 過壓容限選項
  • 額定溫度范圍為-40 °C至+85 °C和-40 °C至+125 °C


關鍵應用

  • 服務器、路由器和個人計算
  • 電視和硬件控制監控器
  • 游戲機和無人機
  • 電池供電應用
  • 汽車應用(ADAS、VCU、DCU和BCM)
  • 監控?cái)z像頭
  • 電信設備


Featured Documents

Latest news and blogs

產品

型號 描述 狀態 快速訪問
NCA9535BY Low-voltage 16-bit I2C and SMBus low-power I/O expander with interrupt output and configuration registers Production
NCA9535BY-Q100 Low-voltage 16-bit I2C and SMBus low-power I/O expander with interrupt output and configuration registers Production
NCA9535PW Low-voltage 16-bit I2C and SMBus low-power I/O expander with interrupt output and configuration registers Production
NCA9535PW-Q100 Low-voltage 16-bit I2C and SMBus low-power I/O expander with interrupt output and configuration registers Production
NCA9539BY Low-voltage 16-bit I2C and SMBus low-power I/O expander with interrupt output, reset pin and configuration registers Production
NCA9539BY-Q100 Low-voltage 16-bit I2C and SMBus low-power I/O expander with interrupt output, reset pin and configuration registers Production
NCA9539PW Low-voltage 16-bit I2C and SMBus low-power I/O expander with interrupt output, reset pin and configuration registers Production
NCA9539PW-Q100 Low-voltage 16-bit I2C and SMBus low-power I/O expander with interrupt output, reset pin and configuration registers Production
NCA9555BY Low-voltage 16-bit I2C and SMBus I/O expander with interrupt output and configuration registers Production
NCA9555BY-Q100 Low-voltage 16-bit I2C and SMBus I/O expander with interrupt output and configuration registers Production
NCA9555PW Low-voltage 16-bit I2C and SMBus I/O expander with interrupt output and configuration registers Production
NCA9555PW-Q100 Low-voltage 16-bit I2C and SMBus I/O expander with interrupt output and configuration registers Production
NCA9595PW Low-voltage 16-bit I2C and SMBus I/O expander with interrupt output, configuration registers and programmable pull-up resistors Production
NCA9595PW-Q100 Low-voltage 16-bit I2C and SMBus I/O expander with interrupt output, configuration registers and programmable pull-up resistors Production
NCA9700DQ Level translating Fm+ I2C bus repeater/accelerator Production
NCA9701AGX vp_NCA9701A Production
PCA9535PW Low-voltage 16-bit I2C and SMBus low-power I/O expander with interrupt output and configuration registers Production
PCA9539PW Low-voltage 16-bit I2C and SMBus low-power I/O expander with interrupt output, reset pin and configuration registers Production
PCA9555PW Low-voltage 16-bit I2C-bus I/O port with interrupt and weak pull-up Production
Visit our documentation center for all documentation

Marcom graphics (1)

文件名稱 標題 類型 日期
XSON8_SOT1089_mk.png plastic, extremely thin small outline package; no leads; 8 terminals; 0.55 mm pitch; 1.35 mm x 1 mm x 0.5 mm body Marcom graphics 2017-01-28

Software (1)

文件名稱 標題 類型 日期
NCA95XX_Arduino_Sketches.zip NCA95XX Arduino? Sketch Examples Software 2023-03-12

如果您有支持方面的疑問,請告知我們。如需獲得設計支持,請告知我們并填寫技術支持表格,我們會盡快回復您。

請?jiān)L問我們的社區論壇聯系我們


交叉參考
